Lathe Dust Collector Downloadable Plan

Reader Jerry Bolin of Prattville, Alabama, sent in this dust-collector idea for mid- and full-size lathes. It attaches to the ways via a pair of shop-made clamps. Convinced of its merit, I had contributing craftsman and turner Bill Sands build Jerry’s collector and test it out, hooking it up to a dust collector, and then to a shop vacuum. While it was never meant to draw in large shavings and chips, it effectively sucked in the fine, hazardous dust from scraping and sanding–the stuff that could otherwise end up in your lungs or cover shop surfaces. Of course the dust collector had more pull, but the
shop vacuum also performed well.
You will be able to download the pdf file from the Thank You page or from the Downloadable Product Email once your order is placed.
Woodcraft Magazine’s Classic™ Project Plans
These plans are the “best of” the projects from Editors of Woodcraft Magazine. Each plan features step by step instructions with detail photographs, exploded illustrations for various project steps, a cut list and cutting diagram, and a Convenience Plus Buying Guide so you know exactly what supplies are required to complete the project. Whether you are a beginner or an accomplished woodworker, the Woodcraft Classic Plan series will have a plan for you!
